Ringer Racing Clutch & Flywheel Kit – VR6 Lonigude with 01E
$1,458.00
Kit includes:
- Ringer Racing Clutch Kit
- Steel Flywheel
- Throw-out Bearing
- Alignment tool
- Flywheel/PP Bolts
*Includes ground shipping within the 48 States only.
Description
This is a Private Label kit built by Clutch Masters exclusively for Ringer Racing
Kit includes:
- Ringer Racing Clutch Kit
- Billet Steel Flywheel – 23 lbs
- Throw-out Bearing
- Alignment tool
- Flywheel and Pressure Plate Bolts
Stage 3
- Heavy-duty street & racing system
- Holding capacity 135% over stock
- Heavy-Duty reinforced pressure plate
- Hi-Leverage pressure ring design
- Ductile Iron Casting
- Sprung hub/cushioned Steel backed disc
- Steel backed Organic/Cerametalic Material
- OEM Pedal feel
Stage 3+
- Heavy-duty street & racing system
- Holding capacity 150% over stock
- Heavy-Duty reinforced pressure plate
- Hi-Leverage pressure ring design
- Sprung hub/cushioned Steel backed disc
- Steel backed Organic/Cerametalic Material
- B7 RS4 Pedal Feel
Stage 4
- Heavy-duty street & racing system
- Holding capacity 200% over stock
- Heavy-Duty reinforced pressure plate
- Hi-Leverage pressure ring design
- Sprung hub/cushioned Steel backed disc
- Full Face Cerametalic Material on both sides
- OEM Pedal feel
Stage 5
- Heavy-duty street & racing system
- Holding capacity 270% over stock
- Heavy-Duty reinforced pressure plate
- Hi-Leverage pressure ring design
- Sprung hub/cushioned Steel backed disc
- Full Face Cerametalic Material on both sides
- B7 RS4 Pedal Feel
Stage 5+
- Modified Stage 5 pressure plate for 8% more clamping load
- Holding capacity 300% over stock
- Heavy-Duty reinforced pressure plate
- Hi-Leverage pressure ring design
- Sprung hub/cushioned Steel backed disc
- Full Face Cerametalic Material on both sides
- Slightly stiffer pedal then the stage 5
6 Puck Drag Clutch kit
Stage 5
- Heavy-duty street & racing system
- Heavy-Duty reinforced pressure plate
- Hi-Leverage pressure ring design
- Sprung hub 6-button iron disk
- Slightly stiffer pedal
Stage 5+
- Modified Stage 5 pressure plate for 8% more clamping load
- Heavy-Duty reinforced pressure plate
- Hi-Leverage pressure ring design
- Sprung hub/cushioned Steel backed disc
- Sprung hub 6-button iron disk
- Slightly stiffer pedal then the stage 5
Hardware Options:
- Standard 12.9 Cap Head Flywheel Bolts
- Custom Clutch Masters ARP Flywheel Bolts
Torque Rating at the Flywheel
- Stage 3 – 585 ft lbs
- Stage 3+ – 700 ft lbs
- Stage 4 – 840 ft lbs
- Stage 5 – 925 ft lbs
- Stage 5+ – 1000 ft lbs
Note: Bolt torque specs:
Standard Flywheel bolts = 70 ft lbs
ARP Flywheel bolts = 45 ft lb, 65 lb and then finish at 85 ft lb
Pressure plate bolts = 25 ft lbs
Dab of loctite on all bolts
*Option to add a Diamond Claw Surface Lock to the flywheel
Surface locks have successfully eliminated fretting (surface welding) in every application customers have placed them in. With an installed thickness of .010″-.012″ a Diamond Claw Surface Lock will not significantly alter assembly spacing. You’ll give yourself a much better chance of the flywheel not coming loose in the first place, and if for some reason it does, you’ll have an extra layer of very hard steel that can prevent the flywheel from damaging your crankshaft.
**Includes ground shipping within the 48 States only. Option tab for orders outside the 48 States. Now offering FedEx 2-day air shipping as a option for orders in the 48 states.
For all other shipping options please contact us.
Additional information
| Brand | |
|---|---|
| Ringer Racing Clutch Kit | Stage 3 Organic/Cerametalic, Stage 3+ Organic/Cerametalic, Stage 4 Cerametalic, Stage 5 Cerametalic, Stage 5+ Cerametalic, Stage 5 Drag Clutch, Stage 5+ Drag Clutch |
| Flywheel Bolts | |
| Surface Lock | No, Yes add Surface Lock |
| Ringer Racing T-shirt - while supplies last | No Thank You, Medium, Large, XL, 2XL |
| Shipping to | #1 – UPS Ground – 48 States, #2 – FedEx 2-Day Air – 48 States, #3 – UPS Ground – HI/AK, #4 – USPS Priority – Puerto Rico, #5 – UPS Ground – Canada |
